3.2.10 High-Definition-Multimedia-Interface (HDMI) Interface

The ULP-COM sA3874i module supports a single HDMI interface with a resolution up to 1920x1080 pixels.

HDMI signals are exposed on the ULP-COM sA3874i edge connector as shown below:

ULP-COM sA3874i Edge finger

TI Cortex A8 CPU

Net Name

Notes

Pin # Pin Name

Pin #

Pin Name

HDMI Differential Signals

P98

HDMI_D0_P

AG19

HDMI_DP0

HDMI_D0+

HDMI
Differential
Data pair
0 output

P99

HDMI_D0_N

AH19

HDMI_DN0

HDMI_D0-

P95

HDMI_D1_P

AG20

HDMI_DP1

HDMI_D1+

HDMI
Differential
Data pair 1
output

P96

HDMI_D1_N

AH20

HDMI_DN1

HDMI_D1-

P92

HDMI_D2_P

AG21

HDMI_DP2

HDMI_D2+

HDMI
Differential
Data pair 2
output

P93

HDMI_D2_N

AH21

HDMI_DN2

HDMI_D2-

P101

HDMI_CK_P

AG18

HDMI_CLKP

HDMI_CK+

HDMI
Differential
clock output

P102

HDMI_CK_N

AH18

HDMI_CLKN

HDMI_CK-

HDMI Support signals

P104

HDMI_HPD

AA26

HDMI_HPDET

HDMI_HPD

HDMI Hot Plug
Detect input

P105

HDMI_CTRL_CK

AF24

HDMI_SCL

HDMI_DDC_SCL_1V8

HDMI dedicated
I2C Clock

P106

HDMI_CTRL_DAT

AG24

HDMI_CNTL_DAT

HDMI_DDC_SDA_1V8

HDMI dedicated
I2C Data

P107

HDMI_CEC

AB27

HDMI_CEC

HDMI_CEC

Not used

The Carrier board must provide voltage translation for the DDC and HPD signals, as well as ESD protection on all
the HDMI signals. The Carrier board ESD protection is important as HDMI is a hot-pluggable interface. A device
such as the Texas Instruments TPD12S016 is recommended. The Kontron ULP-COM Evaluation Board schematic
(KAI 501-146) is useful as an implementation example.
