Kontron SMARC-sA3874i User Manual
Page 21
21
www.kontron.com
User’s Guide
ULP-COM sA3874i Edge finger
LVDS Transmitter
(TI SN75LVDS83B)
LVDS
Channel
Transmit
bit Order
24 bit standard color
mapping
S122
LCD_HS
A4
D24
3
HS
S98
LCD_D5
A6
D22
4
B5
S97
LCD_D4
B5
D21
5
B4
S96
LCD_D3
B6
D20
6
B3
S95
LCD_D2
C6
D19
7
B2
N/C
N/C
A5
D23
3
1
Not Used
S100
LCD_D7
D6
D17
2
B7
S99
LCD_D6
E6
D16
3
B6
S109
LCD_D15
H6
D11
4
G7
S108
LCD_D14
H4
D10
5
G6
S118
LCD_D23
K4
D5
6
R7
S117
LCD_D22
J1
D27
7
R6
S123
LCD_PCK
A2
CLKIN
Pixel clock
The following table shows how the sA3874i LCD pins should be mapped to Thine THC63LVD82, for standard dual
channel LVDS 24 bit color packing. Other LVDS 24 bit mapping can be used with this transmitter. Transmitters
from other vendors may be used as well.
ULP-COM sA3874i Edge finger
LVDS Transmitter
(Thine THC63LVD82)
LVDS
Channel
Transmit
bit Order
24 bit standard color
mapping
Pin #
Pin Name
Pin #
Pin Name
S102
LCD_D8
H1
G10
0
1
G0
S116
LCD_D21
F1
R15
2
R5
S115
LCD_D20
F2
R14
3
R4
S114
LCD_D19
E1
R13
4
R3
S113
LCD_D18
E2
R12
5
R2
S112
LCD_D17
D1
R11
6
R1
S111
LCD_D16
D2
R10
7
R0
