TI PMU TPS659110C
ULP-COM sA3874i Edge
finger
Net name Notes
F6 GPIO1 EN_V_5V0_SYS
V_5V0_SYS Power regulator
enable signal
L2 GPIO2 EN_V_3V3_S0_GPIO2
V_3V3_S0 Power regulator
enable signal
B7 GPIO3 Not used
H7 GPIO4 PGD_V_3V3_S0 V_3V3_S0 Power good signal
G6 GPIO5 PGD_V_1V5_DDR3
V_1V5_DDR3 Power good
signal
G3 GPIO6 EN_V_3V3_S0_GPIO6
V_3V3_S0 Power regulator
enable optional signal
L4 GPIO7 Not used
K5 GPIO8 Not used
5.3 ULP-COM sA3874i I/O
The ULP-COM sA3874i module provides multiple I/O lines for various functions. 12 I/Os lines are used as
interrupt capable GPIOs, which follow ULP-COM hardware specification. GPIO5 PWM output and GPIO6 Tachometer
input support is also provided as per the ULP-COM hardware specification.
Caution! These details are provided for reference. Generally, access to the I/O is abstracted in the Kontron BSP
packages.
GPIO functionality and I/O mapping to the ULP-COM sA3874i connector are shown in the following table:
TI Cortex A8 CPU
ULP-COM sA3874i Edge
finger
Net name Notes
Pin # Pin Name Pin # Pin Name
U6
MCA[2]_ACLKX/GP
0[10]
P108
GPIO0 /
CAM0_PWR#
GPIO0/CAM0_PWR#
Default Function :
Boot code should set this
to output, high
Alternate Function:
CAM0 active low camera
power enable
