Kontron SMARC-sA3874i - Manual (Page 16)

16 www.kontron.com
User’s Guide
Sitara ARM Cortex CPU
LVDS Transmitter
(TI
SN65LVDS93AZ)
Net names
LV
DS
C
ha
nn
el
Tra
ns
mit Bi
t
Or
de
r
18 Bit
standard
Color
mapping
24 Bit/18
bit
compatible
Color
mapping
AC10 VOUT[0]_B_CB_C[6] C6 D19 VOUT0_B[4] 7 B2 B4
Not
Used
Not Used A5 D23 Not Used
3
1 Not Used Not Used
AE15 VOUT[0]_B_CB_C[3] D6 D17 VOUT0_B[1] 2 Not Used B1
AG7 VOUT[0]_B_CB_C[2] E6 D16 VOUT0_B[0] 3 Not Used B0
AH15 VOUT[0]_G_Y_YC[3] H6 D11 VOUT0_G[1] 4 Not Used G1
AH7 VOUT[0]_G_Y_YC[2] H4 D10 VOUT0_G[0] 5 Not Used G0
AB9 VOUT[0]_R_CR[3] K4 D5 VOUT0_R[1] 6 Not Used R1
AD9 VOUT[0]_R_CR[2] J1 D27 VOUT0_R[0] 7 Not Used R0
AD12 VOUT[0]_CLK A2 CLKIN VOUT0_CLK
