3.2.11 Parallel Camera Interface
The ULP-COM sA3874i module supports one parallel camera interface. The parallel camera interface signals are
exposed on the ULP-COM sA3874i edge connector as shown below:
ULP-COM sA3874I Edge finger TI Cortex A8 CPU Net Name Notes
Pin # Pin Name Pin # Pin Name
PCAM SIGNALS
P3 PCAM_D0/CSI1_CK_P AF9 VIN[0]A_D[0] PCAM_D[0] Parallel camera input
data
P4 PCAM_D1/CSI1_CK_N AB11 VIN[0]A_D[1] PCAM_D[1]
P7 PCAM_D2/ CSI1_D0_P AC9 VIN[0]A_D[2] PCAM_D[2]
P8 PCAM_D3/ CSI1_D0_N AE12 VIN[0]A_D[3] PCAM_D[3]
P10 PCAM_D4/CSI1_D1_P AH8 VIN[0]A_D[4] PCAM_D[4]
P11 PCAM_D5/CSI1_D1_N AG16 VIN[0]A_D[5] PCAM_D[5]
P13 PCAM_D6/CSI1_D2_P AH16 VIN[0]A_D[6] PCAM_D[6]
P14 PCAM_D7/CSI1_D2_N AA11 VIN[0]A_D[7] PCAM_D[7]
P16 PCAM_D8/CSI1_D3_P AB15 VIN[0]A_D[8]_BD[
0] PCAM_D[8]
P17 PCAM_D9/CSI1_D3_N AG9 VIN[0]A_D[9]_BD[
1] PCAM_D[9]
S8 PCAM_D10/CSI0_CK_P AH9 VIN[0]A_D[10]_BD
[2] PCAM_D[10]
S9 PCAM_D11/CSI0_CK_N AH17 VIN[0]A_D[11]_BD
[3] PCAM_D[11]
S11 PCAM_D12/CSI0_D0_P AG17 VIN[0]A_D[12]_BD
[4] PCAM_D[12]
S12 PCAM_D13/CSI0_D0_N AF17 VIN[0]A_D[13]_BD
[5] PCAM_D[13]
S14 PCAM_D14/CSI0_D1_P AC12 VIN[0]A_D[14]_BD
[6] PCAM_D[14]
S15 PCAM_D15/CSI0_D1_N AC14 VIN[0]A_D[15]_BD
[7] PCAM_D[15]
