User’s Guide
ULP-COM sA3874I Edge finger TI Cortex A8 CPU Net Name Notes
S4 PCAM_PXL_CK0 AB20 VIN[0]A_CLK PCAM_PXL_CK Parallel camera primary
pixel clock input
P6 PCAM_MCK AE17 VIN[0]B_CLK PCAM_MCK Parallel camera Master
Clock output
S2 PCAM_HSYNC AC20 VIN[0]A_HSYNC PCAM_HSYNC Parallel camera
Horizontal Sync input
S1 PCAM_VSYNC AD20 VIN[0]A_VSYNC PCAM_VSYNC Parallel camera Vertical
Sync input
P5 PCAM_DE AE21 VIN[0]A_DE PCAM_DE Parallel camera Data
Enable input
P115 GPIO7/PCAM_FLD AA20 VIN[0]A_FLD/VIN[0
]B_VSYNC/UART5_R
XD/I2C[2]_SCL/GP2
[1] GPIO7/PCAM_FLD Parallel camera Field
input
PCAM Support signals
S5 I2C_CAM_CK AH26 I2C[3]_SCL I2C_CAM_CK/I2C3
_CK Parallel camera support
link - I2C clock
S7 I2C_CAM_DAT AA24 I2C[3]_SDA I2C_CAM_DAT/I2C
3_DAT Parallel camera support
link - I2C data
P108 GPIO0 / CAM0_PWR# U6 MCA[2]_ACLKX/GP0
[10] GPIO0/CAM0_PWR Camera 0 Power Enable,
active low output.
P110 GPIO2 / CAM0_RST# AC22 VIN[0]A_FLD/CAM_
D[5]/GP0[20] GPIO2/CAM0_RST Camera 0 Reset, active
low output
S57 PCAM_ON_CSI0# GND Camera type selection
signal
S58 PCAM_ON_CSI1# GND Camera type selection
signal
