18 www.kontron.com
User’s Guide
Sitara TI ARM Cortex CPU
ULP-COM sA3874i Edge
finger
Net Name Color
24 bit
Color
map
Pin # Pin Name Pin # Pin Name
AC13 VOUT[0]_R_CR[9] S118 LCD_D23 VOUT0_R[7]
RE
D
R7
AE8 VOUT[0]_R_CR[8] S117 LCD_D22 VOUT0_R[6] R6
AF12 VOUT[0]_R_CR[7] S116 LCD_D21 VOUT0_R[5] R5
AF6 VOUT[0]_R_CR[6] S115 LCD_D20 VOUT0_R[4] R4
AF8 VOUT[0]_R_CR[5] S114 LCD_D19 VOUT0_R[3] R3
AA9 VOUT[0]_R_CR[4] S113 LCD_D18 VOUT0_R[2] R2
AB9 VOUT[0]_R_CR[3] S112 LCD_D17 VOUT0_R[1] R1
AD9 VOUT[0]_R_CR[2] S111 LCD_D16 VOUT0_R[0] R0
AF14 VOUT[0]_G_Y_YC[9] S109 LCD_D15 VOUT0_G[7]
GR
EE
N
G7
AE14 VOUT[0]_G_Y_YC[8] S108 LCD_D14 VOUT0_G[6] G6
AD14 VOUT[0]_G_Y_YC[7] S107 LCD_D13 VOUT0_G[5] G5
AA8 VOUT[0]_G_Y_YC[6] S106 LCD_D12 VOUT0_G[4] G4
AB12 VOUT[0]_G_Y_YC[5] S105 LCD_D11 VOUT0_G[3] G3
AB8 VOUT[0]_G_Y_YC[4] S104 LCD_D10 VOUT0_G[2] G2
AH15 VOUT[0]_G_Y_YC[3] S103 LCD_D9 VOUT0_G[1] G1
AH7 VOUT[0]_G_Y_YC[2] S102 LCD_D8 VOUT0_G[0] G0
AG15 VOUT[0]_B_CB_C[9] S100 LCD_D7 VOUT0_B[7]
B
LU
E
B7
AF15 VOUT[0]_B_CB_C[8] S99 LCD_D6 VOUT0_B[6] B6
AB10 VOUT[0]_B_CB_C[7] S98 LCD_D5 VOUT0_B[5] B5
AC10 VOUT[0]_B_CB_C[6] S97 LCD_D4 VOUT0_B[4] B4
AD15 VOUT[0]_B_CB_C[5] S96 LCD_D3 VOUT0_B[3] B3
AD11 VOUT[0]_B_CB_C[4] S95 LCD_D2 VOUT0_B[2] B2
AE15 VOUT[0]_B_CB_C[3] S94 LCD_D1 VOUT0_B[1] B1
AG7 VOUT[0]_B_CB_C[2] S93 LCD_D0 VOUT0_B[0] B0
