User’s Guide
ULP-COM sA3874i Edge finger
LVDS Transmitter
(Thine THC63LVD82)
LVDS
Channel
Transmit
bit Order
24 bit standard color
mapping
S94
LCD_D1
J5
B11
1
1
B1
S93
LCD_D0
H5
B10
2
B0
S107
LCD_D13
J3
G15
3
G5
S106
LCD_D12
H3
G14
4
G4
S105
LCD_D11
J2
G13
5
G3
S104
LCD_D10
H2
G12
6
G2
S103
LCD_D9
J1
G11
7
G1
S120
LCD_DE
G9
DE
2
1
DE
S121
LCD_VS
H9
VSYNC
2
VS
S122
LCD_HS
J9
HSYNC
3
HS
S98
LCD_D5
J7
B15
4
B5
S97
LCD_D4
H7
B14
5
B4
S96
LCD_D3
J6
B13
6
B3
S95
LCD_D2
H6
B12
7
B2
N/C
N/C
3
1
Not Used
S100
LCD_D7
J8
B17
2
B7
S99
LCD_D6
H8
B16
3
B6
S109
LCD_D15
J4
G17
4
G7
S108
LCD_D14
H4
G16
5
G6
S118
LCD_D23
G1
R17
6
R7
S117
LCD_D22
G2
R16
7
R6
S123
LCD_PCK
F9
CLKIN
Pixel clock
A very good, lower cost alternative to the Thine THC63LVD82 dual channel LVDS transmitter is the TI DS90C187
dual channel LVDS transmitter. A future version of this manual will replace the Thine references with a TI
DS90C187 reference. The module Design Guide is being written up with the TI DS90C187 as the example.
