ULP-COM sA3874i Edge finger TI Cortex A8 CPU Notes
P102 HDMI_CK_N AH18 HDMI_CLKN
P103 GND33
P104 HDMI_HPD AA26 HDMI_HPDET
P105 HDMI_CTRL_CK AF24 HDMI_SCL
P106 HDMI_CTRL_DAT AG24 HDMI_CNTL_DAT
P107 HDMI_CEC AB27 HDMI_CEC
P108 GPIO0/CAM0_PWR# U6 GP0[10]
P109 GPIO1/CAM1_PWR# AA5 GP0[11]
P110 GPIO2/CAM0_RST# AC22 GP0[20]
P111 GPIO3/CAM1_RST# AD23 GP0[27]
P112 GPIO4/HDA_RST# W2 GP1[8]
P113 GPIO5/PWM_OUT AD28 GP1[15]
P114 GPIO6/TACHIN T28 GP1[23]
P115 GPIO7/PCAM_FLD AA20 GP2[1]
P116 GPIO8/CAN0_ERR# M25 GP1[25]
P117 GPIO9/CAN1_ERR# R26 GP1[27]
P118 GPIO10 M26 GP1[28]
P119 GPIO11 W28 GP1[31]
P120 GND34
P121 I2C_PM_CK AC4 I2C[0]_SCL
P122 I2C_PM_DAT AB6 I2C[0]_SDA
P123 BOOT_SEL0# MAX V CPLD
P124 BOOT_SEL1# MAX V CPLD
P125 BOOT_SEL2# MAX V CPLD
P126 RESET_OUT# PMU TPS65911C and MAX V CPLD
P127 RESET_IN#
PMU TPS65911C through Level
