ULP-COM sA3874i Edge finger TI Cortex A8 CPU Notes
P153 VDD_IN7
P154 VDD_IN8
P155 VDD_IN9
P156 VDD_IN10
S1 PCAM_VSYNC AD20 VIN[0]A_VSYNC
S2 PCAM_HSYNC AC20 VIN[0]A_HSYNC
S3 GND13
S4 PCAM_PXL_CK0 AB20 VIN[0]A_CLK
S5 I2C_CAM_CK AH26 I2C[3]_SCL
S6 CAM_MCK Not used
S7 I2C_CAM_DAT AA24 I2C[3]_SDA
S8 CSI0_CK_P\PCAM_D10 AH9 VIN[0]A_D[10]_BD[2]
S9 CSI0_CK_N\PCAM_D11 AH17 VIN[0]A_D[11]_BD[3]
S10 GND14
S11 CSI0_D0_P/PCAM_D12 AG17 VIN[0]A_D[12]_BD[4]
S12 CSI0_D0_N/PCAM_D13 AF17 VIN[0]A_D[13]_BD[5]
S13 GND15
S14 CSI0_D1_P/PCAM_D14 AC12 VIN[0]A_D[14]_BD[6]
S15 CSI0_D1_N/PCAM_D15 AC14 VIN[0]A_D[15]_BD[7]
S16 GND16
S17 AFB0_OUT Not used
S18 AFB1_OUT Not used
S19 AFB2_OUT Not used
S20 AFB3_IN Not used
S21 AFB4_IN Not used
S22 AFB5_IN Not used
