ULP-COM sA3874i Edge finger TI Cortex A8 CPU Notes
S126 LVDS0_N LVDS Transmitter
S127 LCD_BKLT_EN MAX V CPLD
S128 LVDS1_P LVDS Transmitter
S129 LVDS1_N LVDS Transmitter
S130 GND46
S131 LVDS2_P LVDS Transmitter
S132 LVDS2_N LVDS Transmitter
S133 LCD_VDD_EN MAX V CPLD
S134 LVDS_CK_P LVDS Transmitter
S135 LVDS_CK_N LVDS Transmitter
S136 GND47
S137 LVDS3_P LVDS Transmitter
S138 LVDS3_N LVDS Transmitter
S139 I2C_LCD_CK AH26 I2C[3]_SCL
S140 I2C_LCD_DAT AA24 I2C[3]_SDA
S141 LCD_BKLT_PWM MAX V CPLD
S142 LCD_DUAL_PCK MAX V CPLD
S143 GND48
S144 RSVD / EDP_HPD Not used
S145 WDT_TIME_OUT# K6 RSTOUTn_WD_OUTn
S146 PCIE_WAKE# MAX V CPLD
S147 VDD_RTC RTC Power
S148 LID# MAX V CPLD
S149 SLEEP# MAX V CPLD
S150 VIN_PWR_BAD# MAX V CPLD
S151 CHARGING# MAX V CPLD
