ULP-COM sA3874i Edge finger TI Cortex A8 CPU Notes
P24 GbE_MDI2_P Atheros AR8031
P25 GbE_LINK_ACT# Atheros AR8031 and OD driver
P26 GbE_MDI1_N Atheros AR8031
P27 GbE_MDI1_P Atheros AR8031
P28 GbE_CTREF Atheros AR8031
P29 GbE_MDI0_N Atheros AR8031
P30 GbE_MDI0_P Atheros AR8031
P31 SPI0_CS1# AG27 SPI[3]_SCS[1]n
P32 GND6
P33 SDIO_WP AG4 SD1_SDWP
P34 SDIO_CMD P2 SD1_CMD/GP0[0]
P35 SDIO_CD#
P36 SDIO_CK P3 SD1_CLK
P37 SDIO_PWR_EN B8 SDIO_PWR_EN
P38 GND7
P39 SDIO_D0 P1 SD1_DAT[0]
P40 SDIO_D1 P5 SD1_DAT[1]/SDIRQ#
P41 SDIO_D2 P4 SD1_DAT[2]/SDRW#
P42 SDIO_D3 P6 SD1_DAT[3]
P43 SPI0_CS0# AC17 SPI[3]_SCS[0]n
P44 SPI0_CK AE18 SPI[3]_SCLK
P45 SPI0_DIN AC16 SPI[3]_D[1]
P46 SPI0_DO AC21 SPI[3]_D[0]
P47 GND8
P48 SATA_TX_P AB2 SATA_TXP0 Through 100nF capacitor
P49 SATA_TX_N AB1 SATA_TXN0 Through 100nF capacitor
