Kontron SMARC-sA3874i User Manual
Page 19
19
www.kontron.com
User’s Guide
Sitara TI ARM Cortex CPU
ULP-COM sA3874i Edge
finger
Net Name
Color
24 bit
Color
map
AD12
VOUT[0]_CLK
S123
LCD_PCK
VOUT0_CLK
AA10
VOUT[0]_AVID/VOUT[0]_FLD S120
LCD_DE
VOUT0_AVID/LCD_DE
AC11
VOUT[0]_HSYNC
S122
LCD_HS
VOUT0_HSYNC
AB13
VOUT[0]_VSYNC
S121
LCD_VS
VOUT0_VSYNC
