User’s Guide
TI Cortex A8 CPU
ULP-COM sA3874i Edge
finger
Net name Notes
AA5
MCA[2]_AFSX/GP0
[11]
P109
GPIO1 /
CAM1_PWR#
GPIO1/CAM1_PWR#
Default Function :
Boot code should set this
to output, high
Alternate Function:
CAM1 active low camera
power enable
AC22
VIN[0]A_FLD/CAM
_D[5]/GP0[20]
P110
GPIO2 /
CAM0_RST#
GPIO2/CAM0_RST#
Default Function :
Boot code should set this
to output, high
Alternate Function:
CAM0 active low reset
AD23
UART2_TXD/
GP0[27]
P111
GPIO3 /
CAM1_RST#
GPIO3/CAM1_RST#
Default Function :
Boot code should set this
to output, high
Alternate Function:
CAM1 active low reset
W2 GP1[8] P112
GPIO4 /
HDA_RST#
GPIO4/HDA_RST#
Default Function :
Boot code should set this
to output, high
Alternate Function:
HD Audio reset, active low
AD28
GPMC_A[20]/SPI
[2]_SCS[1]#/
GP1[15]
P113 GPIO5/PWM_OUT GPIO5/PWM_OUT
Default Function :
Boot code should set this
to output, high
Alternate Function:
PWM output
T28
GPMC_CS[0]#/
GP1[23]
P114 GPIO6/TACHIN GPIO6/TACHIN
Default Function :
Boot code should set this
to input
Alternate Function:
Tachometer input
AA20
UART5_RXD/I2C
[2]_SCL/GP2[1]
P115 GPIO7/PCAM_FLD GPIO7/PCAM_FLD
Default Function :
Boot code should set this
to input
Alternate Function:
Parallel camera field input
signal
M25
GPMC_CS[2]#/GPM
P116
GPIO8/
GPIO8/CAN0_ERR#
Default Function :
Boot code should set this
