ULP-COM sA3874i Edge finger TI Cortex A8 CPU Notes
P50 GND9
P51 SATA_RX_P AA1 SATA_RXP0 Through 100nF capacitor
P52 SATA_RX_N AA2 SATA_RXN0 Through 100nF capacitor
P53 GND10
P54 SPI1_CS0# AD3 SPI[1]_SCS[0]#
P55 SPI1_CS1# W6 SPI[1]_SCS[1]n
P56 SPI1_CK AC3 SPI[1]_SCLK
P57 SPI1_DIN AA6 SPI[1]_D[0]
P58 SPI1_DO AA3 SPI[1]_D[1]
P59 GND11
P60 USB0_P AG11 USB0_DP
P61 USB0_N AH11 USB0_DM
P62 USB0_EN_OC# MAXV CPLD
P63 USB0_VBUS_DET AG12 USB0_VBUSIN 5V VBUS power
P64 USB0_OTG_ID AG10 USB0_ID
P65 USB1_P AG13 USB1_DP
P66 USB1_N AH13 USB1_DM
P67 USB1_EN_OC# MAXV CPLD
P68 GND12
P69 USB2_P Not used
P70 USB2_N Not used
P71 USB2_EN_OC# Not used
P72 PCIE_C_PRSNT# Not used
P73 PCIE_B_PRSNT# Not used
P74 PCIE_A_PRSNT# L6 GP0[28]
P75 PCIE_A_RST# MAXV CPLD
