Module Hardware Health Function Configuration
Feature Option Description
Module H/W Health
Function
Enabled
Disabled
Enables Hardware Health
Monitoring Device on module
CPU FAN Ticks Per
Revolution
1
2
4
8
Set ‘Ticks per rev’
according to number of
impulses sent by this type
of fan during one full
revolution
CPU Fan Divisor 1
2
4
8
16
32
64
128
Adjust Fan Divisor to allow
for best display when the
rotation is at the edges of
the range. If the value gets
out of range the fan would
be displayed non-working
although still running.
Divisor 1: 8800 rpm
Divisor 2: 4400 rpm
Divisor 4: 2200 rpm
Divisor 8: 1100 rpm
Divisor 16: 550 rpm
Divisor 32: 275 rpm
