Kontron COMe-cXLi2 User’s Guide

www.kontron.com

Specifications

3.1

Functional Specification

Processor: Intel® Atom™ Z5xx Series

CPU:

45nm Z520-XL 1.33 GHz/533 MHz (extended temperature

version)

Cores:

1 (with HTT)

Bus Speed:

533 MHz

Bus/Core Ratio: 11 / 12

Cache:

L1 cache 24KB data/32 KB instruction

L2 cache 512 KB, 8-way

Features:

Hyper-Threading Technology (HTT)

Intel® Virtualization Technology

Execute Disable Bit

Enhanced Intel® Speedstep Technology

Core Sleep States: C0, C1E, C2E, C3, C4E, Intel Deep Power

Down State C6

Instruction Set:

32-bit

Package:

22mm x 22mm

Thermal Spec:

40°C to +85°C

NOTE: Intel Deep Power Down State C6 may not be available in the first early

field test (EFT) samples.

Chipset: Intel® System Controller Hub US15WPT

Speed:

533 MHz FSB

Memory:

On-board DDR2 industrial temperature range (8x1GB – 8x2GB)

USB:

8 x USB 2.0 with one USB client supported

Audio:

Intel® High Definition Audio (24 bit / 96 kHz)

Video:

Single channel 24-bit LVDs, single SDVD channel, no VGA

support

PCI Express:

1x PCIe x 1 lane

In standard versions of the COMe-cXLi2, one PCIe lane is

used by GbE, and the second is used by the PCIe-to-PCI

bridge. When PCIe-to-PCI Bridge is removed, only 1x PCIe

is available as the other is still used by GbE. Because of

the routing decisions for the GbE, only one PCIe lane is

ever available for use even if the GbE is depopulated.
