Kontron COMe-cXLi2 User’s Guide
www.kontron.com
23
Pin Signal Description Type Termination Comment
B72 LVDS_B0- Serial DVO Red- DP-O PU 50R in
US15W
Configurat
ion option
B73 LVDS_B1+ Serial DVO Green+ DP-O PU 50R in
US15W
Configurat
ion option
B74 LVDS_B1- Serial DVO Green- DP-O PU 50R in
US15W
Configurat
ion option
B75 LVDS_B2+ Serial DVO Blue+ DP-O PU 50R in
US15W
Configurat
ion option
B76 LVDS_B2- Serial DVO Blue- DP-O PU 50R in
US15W
Configurat
ion option
B77 LVDS_B3+ Serial DVO+ DP-O PD 50R in
US15W
Configurat
ion option
B78 LVDS_B3- Serial DVO- DP-O PD 50R in
US15W
Configurat
ion option
B79 LVDS_BKLT_EN Backlight Enable O-3.3 PD 100k -
B80 GND_24 Power Ground PWR - -
B81 LVDS_B_CK+ Serial DVO CLK+ nc PU 50R in
US15W
Configurat
ion option
B82 LVDS_B_CK- Serial DVO CLK- nc PU 50R in
US15W
Configurat
ion option
B83 LVDS_BKLT_CT
RL
Backlight Brightness
Control
O-3.3 - -
B84 VCC_5V_SBY +5V Standby PWR - -
B85 VCC_5V_SBY +5V Standby PWR - -
B86 VCC_5V_SBY +5V Standby PWR - -
B87 VCC_5V_SBY +5V Standby PWR - -
B88 RSVD5 Reserved - - -
B89 VGA_RED Not connected nc - not
supported
B90 GND_25 Power Ground PWR - -
B91 VGA_GRN Serial Digital Video
TV-OUT Sync CLK
DP-I - Configurat
ion option
B92 VGA_BLU Serial Digital Video
TV-OUT Sync CLK
DP-I - Configurat
ion option
B93 VGA_HSYNC Serial Digital Video
Field Stall
DP-I - Configurat
ion option
B94 VGA_VSYNC Serial Digital Video
Field Stall
DP-I - Configurat
ion option
B95 VGA_I2C_CK Serial DVO Control
Clock
I/OD - Configurat
ion option
B96 VGA_I2C_DAT Serial DVO Control
Data
I/OD - Configurat
ion option
B97 TV_DAC_A Not connected nc - not
supported
B98 TV_DAC_B Not connected nc - not
