7.6 K-Station / JIDA32 Resources
Table 24: I
2
C
BUS Function
I2C 0 Internal / JIDA I2C #1
I2C 1 SM-Bus
I2C 2 Internal / JIDA I2C #2 (for slow
devices)
I2C 3 SDVO I2C
I2C 4 JILI I2C
Table 25: Storage
Device Function
EEPROM 0 JIDA EEPROM Area1 with 32 Bytes
(free to use)
EEPROM 1 JIDA EEPROM Area 2 with 33 Bytes
(reserved)
Table 26: GPIO
Port Function
IO-Port 0 GPIO Port, Bit 0-3: Input, Bit 4-7:
Output
Table 27: Hardware Monitor
Sensor Function
Temp 0 CPU ACPI Temperature (measured with
Winbond W839786 HWM)
Temp 1 Module Temperature (internal IC
temperature of onboard Winbond
W839786 HWM)
FAN 0 Module CPU fan sensor (measured
with Winbond W839786 HWM)
Voltage 0 Winbond 839786 Voltage Sensor 0:
CoreA
Voltage 1 Winbond 839786 Voltage Sensor 1:
VRAM
Voltage 2 Winbond 839786 Voltage Sensor 2:
+3.3V
