Table 5: connector x1b - row c – Kontron COMe-cXLi2 User Manual
Page 30
Kontron COMe-cXLi2 User’s Guide
www.kontron.com
24
Pin
Signal
Description
Type
Termination Comment
supported
B99
TV_DAC_C
Not connected
nc
-
not
supported
B100
GND_26
Power Ground
PWR
-
-
B101
VCC_12V_13
12V VCC
PWR
-
-
B102
VCC_12V_14
12V VCC
PWR
-
-
B103
VCC_12V_15
12V VCC
PWR
-
-
B104
VCC_12V_16
12V VCC
PWR
-
-
B105
VCC_12V_17
12V VCC
PWR
-
-
B106
VCC_12V_18
12V VCC
PWR
-
-
B107
VCC_12V_19
12V VCC
PWR
-
-
B108
VCC_12V_20
12V VCC
PWR
-
-
B109
VCC_12V_21
12V VCC
PWR
-
-
B110
GND_27
Power Ground
PWR
Note: The termination resistors in this table are already mounted on the COM
Express® module. Refer to the PICMG COM Express® Design Guide for
information about additional termination resistors.
Table 5: Connector X1B - Row C
Pin
Signal
Description
Type
Termination Comment
C1
GND
Power Ground
PWR
-
-
C2
IDE_D7
IDE Data Bus
I/O-
5T
-
-
C3
IDE_D6
IDE Data Bus
I/O-
5T
-
-
C4
IDE_D3
IDE Data Bus
I/O-
5T
-
-
C5
IDE_D15
IDE Data Bus
I/O-
5T
-
-
C6
IDE_D8
IDE Data Bus
I/O-
5T
-
-
C7
IDE_D9
IDE Data Bus
I/O-
5T
-
-
C8
IDE_D2
IDE Data Bus
I/O-
5T
-
-
C9
IDE_D13
IDE Data Bus
I/O-
5T
-
-
C10
IDE_D1
IDE Data Bus
I/O-
5T
-
-
C11
GND
Power Ground
PWR
-
-
C12
IDE_D14
IDE Data Bus
I/O-
5T
-
-
C13
IDE_IORDY
IDE I/O Ready
I/O-
PU 10k 3.3V -
