TDP:

2.3W

Package:

37.5mm x 37.5mm

Integrated Graphics: Intel® Graphics Media Accelerator
500(Intel® GMA 500)

Graphics Memory: Up to 352 MBytes with Intel® Embedded Graphics Driver

(IEGD), up to 256 MBytes with

GMA

Features:

HDTV/HD capable

Video decode acceleration supporting MPEG 2/4/H.260

DirectX®9.0c

OpenGL 2.0

Display Interfaces

CRT:

VGA is not supported from the US15WPT System Controller Hub

Flat Panel:

Single Channel LVDS 18/24bit (JUMPtec Intelligent LVDS

interface – JILI),

resolution up to 1366 x 768 (WXGA), no dithering

Digital Display: SDVO, shares pins with PEG interface on COM Express

connector rows C-D with

resolution up to FullHD 1920x1080.

Storage

SATA:

1x Serial ATA (SATA) supporting up to 1.5 Gbit/sec transfer

rate (PATA-to-SATA bridge)

SATA Features:

Boot, NCQ, Staggered Spinup, Port Multiplier

PATA

1x Parallel ATA (PATA)

Onboard Devices:

Ethernet:

Intel® 82574 10/100/1000 GbE MAC (industrial temperature

version),

Intel® 82574 PHY (Max TDP 0.727W) uses one PCIe lane

Ethernet Features:

WakeOnLAN, PXE Lanboot, Time Sync Protocol Indicator,

Jumbo Frames

TPM:

Infineon™ SLB9635TT1 Trusted Platform Module 1.2, onboard

Watchdog:

Kontron PIC microcontroller (interfaces to chipset

over a watchdog-specific I

C interface)
