Kontron COMe-cXLi2 User Manual
Page 36
Kontron COMe-cXLi2 User’s Guide
www.kontron.com
30
Pin
Signal
Description
Type
Termination Comment
line
5T
D43
PCI_AD26
PCI Address & Data Bus
line
I/O-
5T
-
PCI Bridge
D44
PCI_AD28
PCI Address & Data Bus
line
I/O-
5T
-
PCI Bridge
D45
PCI_AD30
PCI Address & Data Bus
line
I/O-
5T
-
PCI Bridge
D46
PCI_IRQC#
PCI Bus Interrupt
Request C
I-5T
PU 8k2 5V
(S0)
PCI Bridge
D47
PCI_IRQD#
PCI Bus Interrupt
Request D
I-5T
PU 8k2 5V
(S0)
PCI Bridge
D48
PCI_CLKRUN#
PCI Clock Run
O-3,3 PU 8k2 3.3V
(S0)
D49
PCI_M66EN
PCI_M66EN
I-5T
PU 8k2 5V
(S0)
PCI Bridge
D50
PCI_CLK
CLK_PCI_33M_EXT | PCI
Clock 33MHz
O-3,3 -
PCI Bridge
D51
GND
Power Ground
PWR
-
-
D52
PEG_TX0+
Serial DVO Red+
DP-O
PU 50R in
US15W
Configurat
ion option
D53
PEG_TX0-
Serial DVO Red-
DP-O
PU 50R in
US15W
Configurat
ion option
D54
PEG_LANE_RV#
Not connected
nc
-
-
D55
PEG_TX1+
Serial DVO Green+
DP-O
PU 50R in
US15W
Configurat
ion option
D56
PEG_TX1-
Serial DVO Green-
DP-O
PU 50R in
US15W
Configurat
ion option
D57
TYPE2#
Not connected for type
2 module
nc
-
-
D58
PEG_TX2+
Serial DVO Blue+
DP-O
PU 50R in
US15W
Configurat
ion option
D59
PEG_TX2-
Serial DVO Blue-
DP-O
PU 50R in
US15W
Configurat
ion option
D60
GND
Power Ground
PWR
-
-
D61
PEG_TX3+
SDVOB_CLK_P
DP-O
-
-
D62
PEG_TX3-
SDVOB_CLK_N
DP-O
-
-
D63
RSVD
-
nc
-
D64
RSVD
-
nc
-
-
D65
PEG_TX4+
Not connected
nc
-
D66
PEG_TX4-
Not connected
nc
-
-
D67
GND
Power Ground
PWR
-
-
D68
PEG_TX5+
Not connected
nc
-
-
D69
PEG_TX5-
Not connected
nc
-
-
D70
GND
Power Ground
PWR
-
-
D71
PEG_TX6+
Not connected
nc
-
-
