Page 34
Kontron COMe-cXLi2 User’s Guide
www.kontron.com
28
Pin
Signal
Description
Type
Termination Comment
C100
GND
Power Ground
PWR
-
-
C101
PEG_RX15+
Not connected
nc
-
-
C102
PEG_RX15-
Not connected
nc
-
-
C103
GND
Power Ground
PWR
-
-
C104
VCC_12V
12V VCC
PWR
-
-
C105
VCC_12V
12V VCC
PWR
-
-
C106
VCC_12V
12V VCC
PWR
-
-
C107
VCC_12V
12V VCC
PWR
-
-
C108
VCC_12V
12V VCC
PWR
-
-
C109
VCC_12V
12V VCC
PWR
-
-
C110
GND
Power Ground
PWR
-
-
Note: The termination resistors in this table are already mounted on the COM
Express® board. Refer to the PICMG COM Express® Design Guide for
information about additional termination resistors.
Table6: Connector X1B - Row D
Pin
Signal
Description
Type
Termination Comment
D1
GND
Power Ground
PWR
-
-
D2
IDE_D5
IDE Data Bus
I/O-
5T
-
-
D3
IDE_D10
IDE Data Bus
I/O-
5T
-
-
D4
IDE_D11
IDE Data Bus
I/O-
5T
-
-
D5
IDE_D12
IDE Data Bus
I/O-
5T
-
-
D6
IDE_D4
IDE Data Bus
I/O-
5T
-
-
D7
IDE_D0
IDE Data Bus
I/O-
5T
-
-
D8
IDE_REQ
IDE Data Bus
I/O-
5T
-
-
D9
IDE_IOW#
IDE IO Write
O-3,3 -
-
D10
IDE_ACK#
IDE DMA Acknowledge
O-3,3 -
-
D11
GND
Power Ground
PWR
-
-
D12
IDE_IRQ
IDE Interrupt Request
I-5T
PD 10k 3V3
-
D13
IDE_A0
IDE Address Bus
O-3,3 -
-
D14
IDE_A1
IDE Address Bus
O-3,3 -
-
D15
IDE_A2
IDE Address Bus
O-3,3 -
-
D16
IDE_CS1#
IDE Chip Select
Channel 0
O-3,3 -
-
D17
IDE_CS3#
IDE Chip Select
O-3,3 -
-
