Pin Signal Description Type Termination Comment
C63 RSVD Not connected nc - -
C64 RSVD Not connected nc - -
-
C65 PEG_RX4+ Not connected nc -
C66 PEG_RX4- Not connected nc - -
C67 RSVD Not connected nc - -
C68 PEG_RX5+ Not connected nc - -
C69 PEG_RX5- Not connected nc - -
C70 GND Power Ground PWR - -
C71 PEG_RX6+ Not connected nc - -
C72 PEG_RX6- Not connected nc - -
C73 SDVO_DATA SDVO_CTRLDATA I/O-
3,3
- -
C74 PEG_RX7+ Not connected nc - -
C75 PEG_RX7- Not connected nc - -
C76 GND Power Ground PWR - -
C77 RSVD Not connected nc - -
C78 PEG_RX8+ Not connected nc - -
C79 PEG_RX8- Not connected nc - -
C80 GND Power Ground PWR - -
C81 PEG_RX9+ Not connected nc - -
C82 PEG_RX9- Not connected nc - -
C83 RSVD Not connected nc - -
C84 GND Power Ground PWR - -
C85 PEG_RX10+ Not connected nc - -
C86 PEG_RX10- Not connected nc - -
C87 GND Power Ground PWR - -
C88 PEG_RX11+ Not connected nc - -
C89 PEG_RX11- Not connected nc - -
C90 GND Power Ground PWR - -
C91 PEG_RX12+ Not connected nc - -
C92 PEG_RX12- Not connected nc - -
C93 GND Power Ground PWR - -
C94 PEG_RX13+ Not connected nc - -
C95 PEG_RX13- Not connected nc - -
C96 GND Power Ground PWR - -
C97 RSVD Not connected nc - -
C98 PEG_RX14+ Not connected nc - -
C99 PEG_RX14- Not connected nc - -
