PCIe Switch:
0, or 1 PCIe links
See details in section 4.2.1
»
Power Management:
L0-L3, Device Power Management D0-D3hot)
Additional Interfaces:
»
LPC:
Yes, to COM Express A-B connector
»
SMBus:
Yes
»
I
2
C:
fast I
2
C (from US15WPT system controller hub)
»
GPIO:
8 GPIO, 4 GPI and 4 GPO
»
SDIO:
1x onboard microSD/MMC card socket (US15WPT SDIO port #0)
1x SDIO port shared with GPIO signals (US15WPT SDIO port
#1)
SD Card Specification 1.1
SDIO boot supported
Power Management & Misc
»
JIDA:
Yes, JIDA EEPROM
JIDA BIOS support
JILI BIOS support
JIDA16 and JIDA32 BIOS support
AMI Core 8 BIOS
»
K-Station:
Yes
»
Bootlogo:
Yes
»
MARS:
Yes, Charger & Manager Support
»
HWM:
Temperature Monitoring for CPU and Board Temperature
(onboard W83L786 HWM)
HWM for external Winbond ADT7476ARQZ
»
Passive Cooling: Passive and Critical Trip Point
»
ACPI:
ACPI 1.0 / 2.0 / 3.0
»
S-States:
S0, S3, S4, S5
»
Input Voltage: Single supply support with wide range input
Allows 5V only design (such as ETX) or 12V only design (COM
Express)
