Page 74
Kontron COMe-cXLi2 User’s Guide
www.kontron.com
68
Feature
Option
Description
Auto
support if no USB devices are
connected
USB Keyboard
Legacy Support
Enabled
Disabled
Enables legacy support for USB
keyboard
USB Mouse Legacy
Support
Enabled
Disabled
Enables legacy support for USB
mouse
USB Storage
Device Support
Enabled
Disabled
Enables support for USB mass
storage devices
USB 2.0
Controller Mode
FullSpeed
HiSpeed
Configures the USB 2.0 controller
in HiSpeed (480Mbps) or FullSpeed
(12Mbps)
BIOS EHCI Hand-
Off
Disabled
Enabled
This is a workaround for an OS
without EHCI hand-off support.
The EHCI ownership change should
claim by the EHCI driver
Devices Configuration - IDE Configuration
Feature
Option
Description
ATA/IDE
Configuration
Disabled
Enabled
Enables or disables the IDE
interface of US15W SCH.
Primary IDE
Master
Submenu
While entering setup, BIOS auto
detects the presence of IDE
