4.2.10
Miscellaneous Circuits
Speaker
The implementation of this subsystem complies with the COM Express®
Specification. For additional implementation information, refer to the PICMG
COM Express® Design Guide.
Battery
The implementation of this subsystem complies with the COM Express®
specification. For additional implementation information, refer to the PICMG
COM Express® Design Guide on the PICMG website.
In compliance with the EN60950 standard, there are at least two current-
limiting devices (resistor and diode) between the battery and the consuming
component.
I
2
C Bus
The CPLD implementation connects LPC to the I
2
C controller to allow higher
speed I
2
C transactions than in previous I/O implementations.
For additional information, refer to the PICMG COM Express® Design Guide on
the PICMG website and I
2
C application notes and JIDA specifications, which
are available on the Kontron website at
See the Chapter 8, “BIOS Operation” for supported I
2
C features.
SMBus
System Management Bus (SMB) signals are connected to the SMBus controller,
which is located on the US15WPT system controller hub. The SMBus is a 2-wire
bi-directional bus (clock and serial data) used for system management tasks
