Kontron COMe-cXLi2 - Manual (Page 31)

Kontron COMe-cXLi2 User’s Guide
www.kontron.com
25
Pin Signal Description Type Termination Comment
5T (S0)
C14 IDE_IOR# IDE I/O Read I/O-
3,3
- -
C15 PCI_PME# PCI Power Management
Event
I/O-
3,3
PU 10k 3.3V
(A)
Serial
diode,
CPLD
C16 PCI_GNT2# PCI Bus Grant 2 O-3,3 PCI Bridge
C17 PCI_REQ2# PCI Bus Request 2 I-5T PU 8k2 5V
(S0)
PCI Bridge
C18 PCI_GNT1# PCI Bus Grant 1 O-3,3 PCI Bridge
C19 PCI_REQ1# PCI Bus Request 1 I-5T PU 8k2 5V
(S0)
PCI Bridge
C20 PCI_GNT0# PCI Bus Grant 0 O-3,3 PCI Bridge
C21 GND Power Ground PWR - -
C22 PCI_REQ0# PCI Bus Request 0 I-5T PU 8k2 5V
(S0)
PCI Bridge
C23 PCI_RST# PCI Bus Reset O-3,3 - PCI Bridge
C24 PCI_AD0 PCI Address & Data Bus
line
I/O-
5T
- PCI Bridge
C25 PCI_AD2 PCI Address & Data Bus
line
I/O-
5T
- PCI Bridge
C26 PCI_AD4 PCI Address & Data Bus
line
I/O-
5T
- PCI Bridge
C27 PCI_AD6 PCI Address & Data Bus
line
I/O-
5T
- PCI Bridge
C28 PCI_AD8 PCI Address & Data Bus
line
I/O-
5T
- PCI Bridge
C29 PCI_AD10 PCI Address & Data Bus
line
I/O-
5T
- PCI Bridge
C30 PCI_AD12 PCI Address & Data Bus
line
I/O-
5T
- PCI Bridge
C31 GND Power Ground PWR - -
C32 PCI_AD14 PCI Address & Data Bus
line
I/O-
5T
- PCI Bridge
C33 PCI_C/BE1# PCI Bus Command and
Byte enables 1
I/O-
5T
- PCI Bridge
C34 PCI_PERR# PCI Bus Grant Error I/O-
5T
PU 8k2 5V
(S0)
PCI Bridge
C35 PCI_LOCK# PCI Bus Lock I/O-
5T
PU 8k2 5V
(S0)
PCI Bridge
C36 PCI_DEVSEL# PCI Bus Device Select I/O-
5T
PU 8k2 5V
(S0)
PCI Bridge
C37 PCI_IRDY# PCI Bus Initiator
Ready
I/O-
5T
PU 8k2 5V
(S0)
PCI Bridge
C38 PCI_C/BE2# PCI Bus Command and I/O- - PCI Bridge
