Kontron COMe-cXLi2 User’s Guide
www.kontron.com
60
8 BIOS Operation
8.1 The COMe-cXLi2 COM has AMI® BIOS installed on the
onboard8-Mbit firmware hub. Determining the BIOS
Version
To determine the AMI® BIOS version, press the Pause key on your keyboard
immediately, as soon as you see the following text display in the upper left
corner of your screen:
» AMIBIOS © 2006 American Megatrends, Inc.
» BIOS Date: 06/16/08 10:52:49 Ver: 08.00.14
» Kontron® BIOS Version < UXP1RXXX>
» © Copyright 2002-2008 Kontron
8.2 Setup Guide
The AMIBIOS Setup Utility changes system behavior by modifying the BIOS
configuration. The setup program uses a number of menus to make changes and
turn features on or off.
Note: Selecting incorrect values may cause system boot failure. Load setup
default values to recover by pressing .
8.2.1 Start AMI® BIOS Setup Utility
To start the AMI® BIOS setup utility, press when the following string
appears during boot-up:
Press to enter Setup
The Info menu then appears.
The Setup Screen has several sections:
Setup Screen Location Function
Menu Bar Top Lists and selects all
top level menus.
Legend Bar Right side Bottom Lists setup navigation
keys.
Item Specific Help
Window
Right side Top Help for selected item.
Menu Window Left Center Selection fields for
current menu.
