Kontron COMe-cXLi2 User Manual
Page 35
Kontron COMe-cXLi2 User’s Guide
www.kontron.com
29
Pin
Signal
Description
Type
Termination Comment
Channel 1
D18
IDE_RESET#
IDE Hard Drive Reset
O-3,3 -
CPLD
D19
PCI_GNT3#
PCI Bus Grant 3
O-3,3
PCI Bridge
D20
PCI_REQ3#
PCI Bus Request 0
I-5T
PU 8k2 5V
(S0)
PCI Bridge
D21
GND
Power Ground
PWR
-
-
D22
PCI_AD1
PCI Address & Data Bus
line
I/O-
5T
-
PCI Bridge
D23
PCI_AD3
PCI Address & Data Bus
line
I/O-
5T
-
PCI Bridge
D24
PCI_AD5
PCI Address & Data Bus
line
I/O-
5T
-
PCI Bridge
D25
PCI_AD7
PCI Address & Data Bus
line
I/O-
5T
-
PCI Bridge
D26
PCI_C/BE0#
PCI Bus Command and
Byte enables 0
I/O-
5T
-
PCI Bridge
D27
PCI_AD9
PCI Address & Data Bus
line
I/O-
5T
-
PCI Bridge
D28
PCI_AD11
PCI Address & Data Bus
line
I/O-
5T
-
PCI Bridge
D29
PCI_AD13
PCI Address & Data Bus
line
I/O-
5T
-
PCI Bridge
D30
PCI_AD15
PCI Address & Data Bus
line
I/O-
5T
-
PCI Bridge
D31
GND
Power Ground
PWR
-
-
D32
PCI_PAR
PCI Bus Parity
I/O-
5T
-
PCI Bridge
D33
PCI_SERR#
PCI Bus System Error
I/O-
5T
PU 8k2 5V
(S0)
PCI Bridge
D34
PCI_STOP#
PCI Bus Stop
I/O-
5T
PU 8k2 5V
(S0)
PCI Bridge
D35
PCI_TRDY#
PCI Bus Target Ready
I/O-
5T
PU 8k2 5V
(S0)
PCI Bridge
D36
PCI_FRAME#
PCI Bus Cycle Frame
I/O-
5T
PU 8k2 5V
(S0)
PCI Bridge
D37
PCI_AD16
PCI Address & Data Bus
line
I/O-
5T
-
PCI Bridge
D38
PCI_AD18
PCI Address & Data Bus
line
I/O-
5T
-
PCI Bridge
D39
PCI_AD20
PCI Address & Data Bus
line
I/O-
5T
-
PCI Bridge
D40
PCI_AD22
PCI Address & Data Bus
line
I/O-
5T
-
PCI Bridge
D41
GND
Power Ground
PWR
-
-
D42
PCI_AD24
PCI Address & Data Bus I/O-
-
PCI Bridge
