Dynojet 424xLC2: Installation Guide - Manual (Page 45)

3-3
4 W D D Y N O I N S T A L L A T I O N
Unpacking and Inspecting the Dyno
Version 1 Above Ground Model 424x/424xLC
2
Automotive Dynamometer Installation Guide
spacer, 424 hydraulic
movement (2)
P/N 26100000
rail tie assembly (2)
P/N 61314300
spacer, rail clamp (8)
P/N 26152020
rail clamp (4)
P/N 61314700
rail clip (10)
P/N 31619500
calibration arm assembly
P/N 61319001
clevis pin, 3/4 x 4.5" (2)
P/N 32900000
runner assembly (30)
P/N 61319500
hairpin cotter, 
7/16 x 3/4" (2)
P/N 32904080
washer, 1/4", flat (4)
P/N DM150-009-003
weight (4)
P/N 35430899
washer, 3/8", flat (4)
P/N DM150-011-002
bolt, 3/8-16 x 1.5", flange,
hex (12)
P/N 36582471
bolt, 1/4 x 1/2", hex (4)
P/N DM150-011-005
bolt, shoulder, 3/8-16, 
1/2"D x 1"L (8)
P/N 36800973
bolt, 3/8-16 x 1", hex (6)
P/N DM150-019-012
part description part description
