C H A P T E R 1
Dynamometer Specifications and Requirements
Above Ground Model 424x/424xLC
2
Automotive Dynamometer Installation Guide
1-8
C OMPRESSED A IR
The following requirements are needed for the air brake:
• Clean and dry air, between 100-140 psi
• shut off valve
• 1/4-inch NPT pipe thread connector (to attach air to the dyno), if air hose does not
have a 3/8-inch inside diameter
• have a 3/8-inch inside diameter
C OMPUTER S PECIFICATIONS
You will need to provide a computer system to run the Power Core software.
D RILL AND D RILL B IT R EQUIREMENTS
You will need to provide a drill and drill bit capable of drilling holes in concrete. Refer
to Appendix A for more information on installing Red Head Anchors.
• drill bit size: 1/2-inch
• minimum hole depth: 1 5/8-inch (41.2 mm)
description minimum specifications recommended specifications
Operating System Windows XP (service pack 3) or
higher
Windows 7 or later
Processor Dual Core Processor, 2GHz or
faster
Intel Core i5 2.8GHz or faster
Memory 2GB System Ram 4GB System Ram or more
Hard Drive 100GB or larger
(54MB required for program)
500GB or larger
(54 MB required for program)
Monitor/Graphics Card 1280x1024 (SXGA) resolution or
higher
1600x900 resolution or higher
Network Adapter 1 free 10/100 Mbps
RJ45 Ethernet Port
1 free 100Mbps RJ45 or Wireless
External Media CD Rom Drive CD Rom Drive
Printer Printer, if prints or needed Color printer, if prints are needed
