The following describes the procedure to disable printing only from the "192.168.100.10" IP address.
Procedures:
i. Click the first column of Access List row 1.
ii. Enter "192.168.100.10" in the Address field and "255.255.255.255" in the Address Mask field.
iii. Select Reject.
iv. Click the first column of Access List row 2.
v. Enter "0.0.0.0" in the Address field and "0.0.0.0" in the Address Mask field.
vi. Select Permit.
vii. Click Apply New Settings.
c. Enabling and Disabling Printing from Network Addresses
You can enable printing from the "192.168" network address and disable printing from the "192.168.200" network address. However, the example below describes how to enable printing from the "192.168.200.10" IP address.
Procedures:
i. Click the first column of the Access List row 1.
ii. Enter "192.168.200.10" in the Address field and "255.255.255.255" in the Address Mask field.
iii. Select Permit.
iv. Click the first column of the Access List row 2.
v. Enter "192.168.200.0" in the Address field and "255.255.255.0" in the Address Mask field.
vi. Select Reject.
vii. Click the first column of the Access List row 3.
viii. Enter "192.168.0.0" in the Address field and "255.255.0.0" in the Address Mask field.
ix. Select Permit.
x. Click Apply New Settings.
NetWare
Purpose:
To configure detailed settings for IPX/SPX and NetWare.
Values:
IPX/SPX
Settings
Frame Type
Auto Specifies the active frame type automatically.
Ethernet II Selects Ethernet II frame type.
Ethernet 802.3 Selects IEEE802.3 frame type.
Ethernet 802.2 Selects IEEE802.2 frame type.
Ethernet SNAP Selects SNAP frame type.
Current Frame
Type
Displays the current frame type.
Network
Address
Displays the IPX network address.
NetWare
Device Name* 1
Specifies the printer name up to 47 alphanumeric characters.
For PServer Mode, set the Print Server Name (Print Server Object Name). The original setting remains valid if no input is made.
Active Mode
Directory: PServer Mode Selects this option when using in Directory: PServer Mode.
Bindery: PServer Mode Selects this option when using in Bindery: PServer Mode.
Tree Name* 1 Specifies the tree name up to 32 alphanumeric characters. Configure this item only when Directory: PServer Mode is selected.
Context Name Specifies the context name of the Print Server Object up to 255 alphanumeric characters. Configure this item only when Directory: PServer Mode is selected.
File Server
Name*
1
Specifies the file server name up to 47 alphanumeric characters. Configure this item only when Bindery: PServer Mode is selected.
Polling
Interval
Sets the time interval from when print data enters the print queue until printing starts. The setting range is from 1 to 1000 seconds. The original setting remains valid if no input is made. Configure this item only when
Bindery: PServer Mode or Directory: PServer Mode is selected.
Password Sets the print server password up to 32 alphanumeric characters. Configure this item only when Bindery: PServer Mode or Directory: PServer Mode is selected.
