* Only displayed when an optional network protocol adapter is installed.
IPX/SPX
Purpose:
To configure the IPX/SPX settings. The change becomes effective after the printer is turned off and then on again.
Values:
Auto* Automatically sets the frame type.
Ethernet II Uses the Ethernet II frame type.
Ethernet 802.3 Uses the IEEE802.3 frame type.
Ethernet 802.2 Uses the IEEE802.2 frame type.
Ethernet SNAP Uses the SNAP frame type.
NOTE: This item is only displayed when an optional network protocol adapter is installed.
IP Filter
Purpose:
To block data received from certain IP addresses through the wired or wireless network. You can set up to five IP
addresses. The change becomes effective after the printer is turned off and then on again.
Values:
No. n/Address
(n is 1-5.)*
1
Sets the IP address for Filter n.
No. n/Mask
(n is 1-5.)*
1
Sets the address mask for Filter n.
No. n/Mode (n is 1-5.)*
1
Off* Disable the IP Filter feature for Filter n.
Accept Accepts an access from the specified IP address.
Reject Rejects an access from the specified IP address.
* 1 This item is only available for LPD or Port9100.
IEEE 802.1x
Purpose:
To disable the IEEE 802.1x authentication. The change becomes effective after the printer is turned off and then on again.
NOTE: This item is only displayed when the IEEE 802.1x authentication is enabled and the optional network
protocol adapter is installed, and also when the optional wireless printer adapter is not installed.
Reset LAN
Purpose:
To initialize wired network data stored in NV (non-volatile) memory. After executing this function and rebooting the
printer, all wired network settings are reset to their default values.
Adobe Protocol
Purpose:
