Subnet Mask
Manually sets the subnet mask.
It is specified using the format nnn.nnn.nnn.nnn. Each octet that makes up nnn.nnn.nnn.nnn is a
value in the range of 0 to 255. (255.255.255.255 cannot be specified as the subnet mask.)
Gateway Address
Manually sets the gateway address.
It is specified using the format nnn.nnn.nnn.nnn. Each octet that makes up nnn.nnn.nnn.nnn is a
value in the range of 0 to 254. 127 and any value in the range of 224 to 254 cannot be specified
for the first octet of a gateway address.
Apply New
Settings
After you complete the settings, press the Apply New Settings button to apply the changes.
Restart printer to
apply new
settings
Press the Restart printer to apply new settings button to apply the changes.
Network Settings
Purpose:
To display the server settings of the Dell Printer Configuration Web Tool.
NOTE: When the printer is connected to the local port, this setting cannot be displayed.
Values:
Display Displays the server settings of the Dell Printer Configuration Web Tool.
Display of EWS
Off Disable to display the server settings of the Dell Printer Configuration Web Tool.
On* Enable to display the server settings of the Dell Printer Configuration Web Tool.
Diagnosis
The Diagnosis tab includes the Chart Print and Environment Sensor Info pages.
NOTE: Values marked by an asterisk (*) are the factory default menu settings.
Chart Print
Purpose:
To various charts that can be used for the printer's diagnosis.
Values:
Pitch
Configuration
Chart
Outputs full halftone pages for yellow, magenta, cyan, and black. Also outputs pages to check the
pitch. A total of five pages are output. The chart is output to A4 or Letter size paper.
Ghost
Configuration
Chart
Outputs a chart to check for ghost printing. One page is output. The chart is output to A4 or Letter
size paper.
4 Colors
Configuration
Chart
Bands of yellow, magenta, cyan, and black are output with varying density. One page is output.
The chart is output to A4 or Letter size paper.
MQ Chart Outputs charts to check for the binding in A4 or Letter.
Alignment Chart
Outputs a chart to check for proper alignment of the print image on the paper. One page is output.
The chart is output to A4 or Letter size paper.
PHD Refresh
Configuration
Outputs a chart to check the light fatigue of the drums of the print cartridges. One page is output.
The chart is output to A4 or Letter size paper.
