Understanding the Tool Box Menus
Printer Settings Report
Printer Maintenance
Diagnosis
The Tool Box allows you to view or specify the printer settings. You can also diagnose the printer settings by using the
Tool Box.
The Tool Box consists of the Printer Settings Report, Printer Maintenance, and Diagnosis tabs.
NOTE: A Password dialog box appears the first time you try to change settings on ToolBox when Panel Lock is
set on the printer. In this case, input the password you specified, and click OK to apply the settings.
Printer Settings Report
The Printer Settings Report tab includes the Printer Information, Menu Settings, Reports, Network Settings, and
TCP/IP Settings pages.
NOTE: Values marked by an asterisk (*) are the factory default menu settings.
Printer Information
Purpose:
To display the printer's system information.
Values:
Dell Service Tag Number Displays Dell's service tag number.
Printer Serial Number Displays the printer's serial number.
Printer Type Displays the type of printing for the printer. Color Laser is displayed normally.
Asset Tag Number Displays the printer's asset tag number.
Memory Capacity Displays the memory capacity.
Processor Speed Displays the processing speed.
Firmware Version Displays the version of the controller.
Network Firmware Version Displays the NIC version.
MCU Firmware Version Displays the version of the MCU firmware.
Printing Speed (Color) Displays the speed for color printing.
Printing Speed (Monochrome) Displays the speed for monochrome printing.
Menu Settings
Purpose:
To display the printer's menu settings.
Values:
Power Saver
Timer Mode 1
Displays the amount of time before the printer enters the power saver timer mode 1
after it finishes a job.
Power Saver Displays the amount of time before the printer enters the power saver timer mode 2
