c. Select Network and Sharing Center.

d. Select Connect to a network.

e. Select dell_device from the network items listed in the available network list, and click Connect.

2. Check the IP address assigned by AutoIP on the printer.

a. Press Menu on the printer control panel.

b. Scroll down and select Admin Menu.

c. Scroll down and select Network.

d. Scroll down and select TCP/IP.

e. Scroll down and select IPv4.

f. Scroll down and select IP Address.

(Default IP address range: 169.254.xxx.yyy)

IP Address

169.254.000.041

*

3. Check that the IP address on your computer is assigned by DHCP.

4. Open Dell Printer Configuration Web Tool using WEB browser.
