Width - 76.2 mm (3.00 inches) to 220 mm (8.66 inches)

Length - 127 mm (5.00 inches) to 355.6 mm (14.00 inches)

Loading the MPF

In addition to plain paper, the MPF can be used various other sizes and types of print media such as envelopes, and

transparencies.

1. Gently pull open the MPF cover.

2. Slide the width guides to the edge of the tray. The width guides should be fully extended.

3. Insert all media facing down and top edge first into the MPF.

NOTE:

Do not force the print media into the single sheet feeder.

4. Slide both width guides until they rest lightly against the edge of the print media stack.

NOTE:

Do not force the print media into the single sheet feeder.
