Installing System Components
109
3 Route the fan power cable through the adjacent slot in the chassis, and
connect the cable to the FAN1 connector on the system board (see
Figure 6-1).
4 Replace the RAID battery and battery carrier, if applicable (see "Installing
5 Close the expansion card cover (see Figure 3-7).
6 Replace the system cover (see "Installing the System Cover" on page 67).
Removing the System Fan
CAUTION:
Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized by Dell is not covered
by your warranty. Read and follow the safety instructions that came with the
product.
1 Turn off the system and attached peripherals, and disconnect the system
from the electrical outlet and from the peripherals.
2 Remove the system cover (see "Removing the System Cover" on page 66).
3 Remove the processor airflow shroud (see "Removing the Processor Airflow
4 Disconnect the fan’s power cable from the system board (see Figure 6-1).
5 Press and hold the fan release tab, then slide the fan towards the bottom of
the chassis and out of the securing slots.
