The ‘MAX’ button allows you to select the “0”, “1”, “2”, “3”, “4” or “5” state for each “OUT” condition.
The ‘MENU’ button stores the selected values for each “OUT” condition changed and advances the meter to the
next configuration (“OT.SC.OF”).
Every underlined item is the factory preset value.
9.2.17 OT.SC.OF (Output Scale And Offset)
Output scale and offset is used to calibrate your optional analog output to correspond to the engineering units you
desire.
MENU BUTTON
MAIN MENU
MIN/MAX/*
BUTTON SUB
MENU 1 MIN/MAX MENU **
BUTTON
SUB MENU 2 DESCRIPTION
OUTPUT SCALE
AND OFFSET
READ 1 Item #1 of Coordinate #1.
000000. (“000000.”) Enter the first value displayed by the meter.
OUTPT1 Item #2 of Coordinate #1.
00.0000 (“04.0000”) Enter first desired output value.
READ 2 Item #1 of Coordinate #2.
000000. (“100000.”) Enter the second value displayed by the meter.
OUTPT2 Item #2 of Coordinate #2.
“OT.SC.OF”:
00.0000 (“20.0000”) Enter second desired output value.
* The ‘MIN’ button allows you to sequence through “READ 1”, “OUTPT1”, “READ 2”, and “OUTPT2” headings.
The ‘MAX’ button sends you to the value corresponding to “READ 1”, “OUTPT1”, “READ 2”, and “OUTPT2” so you
can change it (go to the SUB MENU 2 item).
** The ‘MIN’ button allows you to step through the digits of the applicable number being changed.
The ‘MAX’ button changes the value of the digit to be displayed.
The ‘MENU’ button stores the selected values for each input required in “OT.SC.OF”. After the last value (“READ
2”) has been entered and the ‘MENU’ button is pressed, the meter display will advance to “BAUD”.
Every underlined item is the factory preset value.
9.2.18 BAUD (Baud Rate)
Baud is used to select the baud rate for communication via the optional RS-232 or RS-485 communications boards.
The choices are 300, 600, 1200, 2400, 4800, 9600, and 19200.
MENU BUTTON
MAIN MENU
MIN/MAX/MENU *
BUTTON SUB MENU DESCRIPTION
BAUD RATE
“00300”
“00600” Select baud rate for communications via RS-232 or RS-485
“01200”
“02400”
“04800”
“09600”
“BAUD”:
“19200”
* Press the ‘MIN’ button to show “00300”, “00600”, “01200”, “02400”, “04800”, “09600”, or “19200”.
