MENU BUTTON
MAIN MENU
MIN/MAX/MENU *
BUTTON SUB MENU DESCRIPTION
ALARMS 1 & 2 DEADBAND
“0000”
“AL DB”:
(“0020”)
Hysteresis for (with system decimal points) Alarms 1 & 2
(Programmable from “0000” to “9999”)
* Press the ‘MIN’ button to show the value on the display.
The ‘MIN’ button also allows you to sequence through the digits of the number being changed.
The ‘MAX’ button changes the value of the digit to be displayed.
Press the ‘MENU’ button to store the changes and advances the meter to the next configuration (“OUT.CNF”).
The underlined item is the factory preset value.
9.2.16 OUT.CNF (Output Configuration)
Output configuration is used to select:
• whether or not to send data to the optional analog output board [OUT.1]
• the analog output signal of 0-10 V dc or 4-20 mA DC [OUT.2]
• whether or not to send data to the optional BCD output board [OUT.3]
• to send peak value via the optional BCD output board [OUT.4]
• to select type of BCD output [OUT.5]
• enable or disable the flashing display [OUT.6]
MENU BUTTON
MAIN MENU
MIN/MAX/MENU *
BUTTON SUB MENU DESCRIPTION
OUTPUT CONFIGURATION
Data on the Analog Output Board:
“OUT.1=0” Disabled
“OUT.1=1” Enabled
Analog Output Mode:
“OUT.2=0” 0-1 V, 0-5 V, 1-5 V, 0-10 V
“OUT.2=1” 0-20 mA or 4-20 mA
Data out on Parallel BCD Board:
“OUT.3=0” Disabled
“OUT.3=1” Enabled
Type of data out on BCD Board:
“OUT.4=0” Display
“OUT.4=1” Peak
BCD Output:
“OUT.5=0” Used for standard parallel printers.
“OUT.5=1” Used for Specialty printers.
Type of Display Flashing:
“OUT.6=0” Disabled - display flashing.
“OUT.CNF”:
“OUT.6=1” SP1 active - display flashing.
“OUT.6=2” SP2 active - display flashing.
“OUT.6=3” SP3 active - display flashing.
“OUT.6=4” SP4 active - display flashing.
“OUT.6=5” any SP active - display flashing.
* The ‘MIN’ button allows you to sequence through OUT.1, OUT.2, OUT.3, OUT.4, OUT.5, and OUT.6.
