PRESS
THEN PRESS
(TO CHANGE
IF
REQUIRED) UNTIL
DISPLAY
SHOWS COMMENTS
‘MENU’ “IN.SC.OF” Press the ‘MENU’ button until the display shows “IN.SC.OF” Input
Scale and Offset.
‘MIN’ “INPUT1” Press the ‘MIN’ button and the display will show “INPUT1”.
‘MIN’ “XXXXXX” Press the ‘MIN’ button and the display will show some 6-digit
number.
‘MENU’ “IN.SC.OF” Press the ‘MENU’ button until the display shows “IN.SC.OF” Input
Scale and Offset.
‘MIN’ “INPUT1” Press the ‘MIN’ button and the display will show “INPUT1”.
‘MIN’ “XXXXXX” Press the ‘MIN’ button and the display will show some 6-digit
number.
‘MAX’ ‘MIN’ “000000.” Using the ‘MAX’ button to change the value of the flashing digit and
the ‘MIN’ button to scroll to the next digit to the right, enter “000000.”
on the display.
‘MENU’ “READ 1” Press the ‘MENU’ button and the display will show ‘READ 1".
‘MIN’ “XXXXXX” Press the ‘MIN’ button and the display will show some 6-digit
number.
‘MAX’ “000000.” Using the ‘MAX’ button to change the value of the flashing digit and
the ‘MIN’ button to scroll to the next digit to the right, enter “000000”
on the meter.
‘MENU’ “INPUT2” Press the ‘MENU’ button and the display will show “INPUT2”.
‘MIN’
‘MIN’
“XXXXXX” Press the ‘MIN’ button and the display will show some 6-digit
number.
‘MAX’ “100000.” Using the ‘MAX’ button to change the value of the flashing digit and
the ‘MIN’ button to scroll to the next digit to the right, enter “000000.”
on the display.
‘MENU’ “READ 2” Press the ‘MENU’ button and the display will show “READ 2".
‘MIN’
‘MIN’
“XXXXXX” Press the ‘MIN’ button and the display will show some 6-digit
number.
‘MAX’ ‘MIN’ “100000.” Using the ‘MAX’ button to change the value of the flashing digit and
the ‘MIN’ button to scroll to the next digit to the right, enter “100000.”
on the display.
‘MENU’ “STORED” Press the ‘MENU’ button to store your selection and the display will
momentarily show “STORED” then “DEC PT”.
Proceed with the following steps for positioning your decimal point position:
PRESS
THEN
(TO CHANGE
PRESS IF
REQUIRED) UNTIL
DISPLAY
SHOWS COMMENTS
‘MENU’ “DEC PT” Press the ‘MENU’ button until the display shows “DEC PT”.
‘MIN’ ‘MAX’ “FFF.FFF” Press the ‘MIN’ button and the display will show “FFFFFF.” Or the
previously selected position. Press the ‘MAX’ button to select the
decimal point position you require, the meter displays the previously
selected decimal point location within the “F’s”.
‘MENU’ “CNT BY” Press the ‘MENU’ button to store your decimal point selection and
the meter will momentarily display “STORED” only if you have made
a change and then “CNT BY”.
You are now ready to scale your meter using Input Scale and Offset (“IN.SC.OF”) without connecting a sensor or
signal source to your meter.
8.4.2 Scaling Your Meter
Scaling your meter without a sensor or a signal source connected is easily accomplished by using one of the
calculated scale factors as shown in Figure 8-1.
