“SPC.3=1” Filtered
Setpoint 2 Active zone:
“SPC.4=0” Above
“SPC.4=1” Below
Setpoint 2 open-collector or relay output Active ON or OFF:
“SPC.5=0” On
“SPC.5=1” Off
Filtered/unfiltered reading compared with Setpoint 2 value:
“SPC.6=0” Unfiltered
“SPC.6=1” Filtered
Setpoints 1 & 2 action:
“SPC.7=0” Enabled
“SPC.7=1” Disabled
Setpoint 1 & 2 LEDs action:
“SPC.8=0” Enabled
“SPC.8=1” Disabled
* The ‘MIN’ button allows you to sequence through SPC.1, SPC.2, SPC.3, SPC.4, SPC.5, SPC.6, SPC.7 and
SPC.8.
The ‘MAX’ button allows you to select the “0” or “1” state for each “SPC” condition.
The ‘MENU’ button stores the selected values for each “SPC” condition changed and advances the meter to the
next configuration (“AL CNF”).
Every underlined “0” or “1” is the factory preset value.
9.2.11 AL CNF (Alarm Configuration)
Refer to Section 10 for an in-depth discussion of these features.
Alarm configuration is used to select:
• the active zone for each alarm point to above or below the setting [ALC.1 & ALC.4]
• whether the open-collector output is on or off [ALC.2 & ALC.5]
• whether the readings compared with the alarm points are filtered or unfiltered [ALC.3 & ALC.6]
• enabled or disabled alarm points [ALC.7]
MENU BUTTON
MAIN MENU MIN/MAX/MENU *
BUTTON SUB MENU DESCRIPTION
ALARMS 1 & 2 (SETPOINTS 3 & 4) CONFIGURATIONS
Alarm 1 Active zone (Setpoint 3):
“ALC.1=0” Above
“ALC.1=1” Below
Alarm 1 open-collector or relay output Active ON or OFF:
“ALC.2=0” On
“ALC.2=1” Off
Filtered/unfiltered reading compared with Alarm 1 (Setpoint 3) value:
“ALC.3=0” Unfiltered
“ALC.3=1” Filtered
Alarm 2 Active zone (Setpoint 4):
“ALC.4=0” Above
“AL CNF”:
“ALC.4=1” Below
