Record your “INPUT1” and “READ 1” numbers, and your “INPUT2” and “READ 2” numbers, record them below and
proceed as follows:
Example
INPUT1=
000003.
READ 1 = 000000.
INPUT2 = 100018.
READ 2 = 068000.
For the purpose of this example, we will use the numbers described above for the following procedure:
PRESS
THEN
PRESS (TO
CHANGE IF
REQUIRED) UNTIL
DISPLAY
SHOWS COMMENTS
‘MENU’ “IN.SC.OF” Press the ‘MENU’ button until the display shows “IN.SC.OF” Input
Scale and Offset.
‘MIN’ “INPUT1” Press the ‘MIN’ button and the display will show “INPUT1”.
‘MIN’ “XXXXXX” Press the ‘MIN’ button and the display will show some 6-digit
number.
‘MAX’ ‘MIN’ “000003.” Using the ‘MAX’ button to change the value of the flashing digit
and the ‘MIN’ button to scroll to the next digit to the right, enter
your “INPUT 1” number on the display.
‘MENU’ “READ 1” Press the ‘MENU’ button and the display will show “READ 1".
‘MIN’ “XXXXXX” Press the ‘MIN’ button and the display will show some 6-digit
number.
‘MAX’ ‘MIN’ “000000.” Using the ‘MAX’ button to change the value of the flashing digit
and the ‘MIN’ button to scroll to the next digit to the right, enter the
engineering value that you want your “INPUT 1” number to display
on the meter.
‘MENU’ “INPUT2” Press the ‘MENU’ button and the display will show “INPUT2”.
‘MIN’ “XXXXXX” Press the ‘MIN’ button and the display will show some 6-digit
number.
‘MAX’ ‘MIN’ “100018.” Using the ‘MAX’ button to change the value of the flashing digit
and the ‘MIN’ button to scroll to the next digit to the right, enter
your “INPUT 2” number on the display.
‘MENU’ “READ 2” Press the ‘MENU’ button and the display will show ‘READ 2".
‘MIN’ “XXXXXX” Press the ‘MIN’ button and the display will show some 6-digit
number.
‘MAX’ ‘MIN’ “068000.” Using the ‘MAX’ button to change the value of the flashing digit
and the ‘MIN’ button to scroll to the next digit to the right, enter the
engineering value you want your “INPUT 2” to display.
‘MENU’ “STORED” Press the ‘MENU’ button to store your selection and the display
will momentarily show “STORED” then “DEC PT”.
Now you are ready to position your decimal point position by completing the following steps:
8.3.3 To Select Decimal Point Position (DEC PT)
The following is the procedure for selecting your decimal point position.
PRESS
THEN PRESS
(TO CHANGE
IF REQUIRED) UNTIL DISPLAY
SHOWS COMMENTS
‘MENU’ “DEC PT” Press the ‘MENU’ button until the display shows “DEC PT”.
‘MIN’ ‘MAX’ “FFF.FFF” Press the ‘MIN’ button and the display will show “FFFFFF.”or
the previously selected position. Press the ‘MAX’ button to
select the decimal point position you require, the meter
displays the previously selected
