Figure 5-8. Relay Option Board
Figure 5-9. 4-Relay Option Board
The Analog option board has been
updated. The figure shown is the
latest version.
Some older versions of the analog
output cards are not compatible with
dc-powered meters.
Check the J12 connector on the
main board to ensure it has a 10
position connector.
S1-A does
not need to
be
installed.
Figure 5-10. Analog Output Option Board
CF 67 12 M1291/N/0403 11279ML-02 Rev. A
