Great Plains Manufacturing, Inc. Adjustments 65
03/12/2012 401-226M-A
Singulator Plus™ Meter Wheel Replace-
ment
Choose the correct seed meter wheel for the type of
seed you will be using. Be sure to use the same wheel
type on all meters.
Meter Wheels Not Interchangeable:
Seed meter wheels for the 25 Series row units are made of a
green color material and are not interchangeable with the
other Great Plains seed meter wheels for other machines. Use
only green wheels in 25 Series row units.
1. Clean out meter. For more information, see “Meter
Removal” on page 63
Refer to Figure 95
2.
Push in spring-loaded wheel retainer and make
1 ⁄
4
turn. Pull off wheel retainer and spring.
Refer to Figure 96
3.
Pry the seed meter wheel out about 1 ⁄
4
inch (6mm)
using the tool stored under the walkboard, and spin
backward to clean out seeds from top pockets.
FigureSpacer:
Refer to Figure 97
4.
Remove seed meter wheel.
FigureSpacer:
Figure 95
Singulator Wheel Retainer
22911
FigureSpacer:
Figure 96
Pry Meter Wheel
22913
FigureSpacer:
Figure 97
Remove Wheel
25274
