Frame-Mounted Coulters
Refer to Figure 67
At the shaft
, adjust the coulter depth for a running
depth of 4 to 4 1 ⁄
2
in (10.2 to 11.4cm) below ground
level if off row, if on row as a no-till coulter operate at
planting depth only
. Refer to the Vantage I manual
(204-376M) for further adjustments.
Do not adjust the spring tension. It is factory pre-set.
FigureSpacer:
Vantage I Applicator
Refer to Figure 68
At the back plate
, adjust the tine height for a running
depth of 1in (2.5cm) below ground level . Refer to
the Vantage I manual (204-376M) for further adjust-
ments.
FigureSpacer:
Figure 67
Frame-Mount Coulter
25392
1
4
3
2
1
2
3
4
FigureSpacer:
Figure 68
Vantage I Applicator
22951
5
3
6
5
6 3
