Replace/Add Fittings
99. Select one new:
811-073C TE 3/4MJIC 3/4MJIC 3/4FJIC
Refer to Figure 70 on page 62
100. At the fan return line, disconnect:
811-077C TE 3/4MORB 3/4MJIC 3/4MJIC
811-150C EL 3/4FJIC 3/4MJIC
Insert the tee at this connection.
101. Select one new:
811-725C EL 90 3/4MJIC
Refer to Figure 70 on page 62
102. Locate the existing tee
that connects the return
line riser hose to the hydraulic drive motor return
hose and one of the valve port T hoses .
Remove that tee . It is not re-used.
Use a new elbow to connect the hydraulic drive
motor return hose and the valve port T hose .
103. Select one each new:
811-725C EL 90 3/4MJIC
851-053C HH3/8R2 046 3/4FJIC
Use the elbow to connect the hose to the
existing return riser hose , and the cooler outlet.
Connect Remaining Hoses
Only hoses that are added, removed or disturbed are
identified.
Continue at “Charge and Test” on page 64.
411-037A and 411-038A Part Identification
Hydraulic Connections Callout Part Part Description Status
Pump Outlet to Pivot Pressure Hose 811-663C HH3/8R2 225 3/4FJIC New
Pivot Pressure Hose to Riser Pressure Hose 811-664C HH3/8R2 38 3/4FJIC Left in place
Valve Port T to Motor Return Elbow 811-125C HH3/8R2 082 3/4FJIC Re-connect
New Drive Motor Return Elbow 811-725C EL 90 3/4MJIC New
Drive Motor Return Hose to New Elbow 811-980C HH3/8R2 047 3/4FJIC Re-connect
Second Fan Motor Outlet Tee 811-073C TE 3/4MJIC 3/4MJIC 3/4FJIC New
Motor Outlet Tee to Cooler Inlet 811-268C HH1/2R2 048 3/4FJIC New
Cooler Outlet to Return Riser Hose Elbow 851-053C HH3/8R2 046 3/4FJIC New
New Return Riser Elbow 811-725C EL 90 3/4MJIC New
Return Riser Hose to Return Pivot Hose 811-237C HH3/8R2 174 3/4FJIC Left in place
Return Pivot Hose to Reservoir Return Hose 851-031C HH3/8R2 041 3/4FJIC Left in place
Reservoir Return Hose to Reservoir Inlet 851-163C HH3/8R2 045 3/4FJIC MJIC New
Reservoir Outlet to Pump Inlet 851-164C HH1R4 60 1 5/8FJIC New
