847a and 411-165a flow control hydraulics – Great Plains PTO Kits Single-Section User Manual
Page 60
56
Single-Section PTO Pumps
Great Plains Manufacturing, Inc.
401-885M
2014-06-16
401-847A and 411-165A Flow Control Hydraulics
401-847A and 411-165A
Hose Identification
Hydraulic Connections
Callout
Hose
Hose Description
Elbow at Reservoir Outlet
841-815C
EL 1 5/16FJIC 1 5/16MJIC
Reservoir Outlet to Pump Inlet
841-849C
HH1R4 168 1 5/16FJIC
Pump Outlet to Valve Port P
811-807C
HH1/2R2 120 3/4FJIC
Valve Port M to Fan Motor Inlet B
811-059C
HH1/2R2 080 3/4FJIC
Tee at Fan Motor Outlet A
811-073C
TE 3/4MJIC 3/4MJIC 3/4FJIC
Valve Port T to Fan Motor Tee
811-059C
HH1/2R2 080 3/4FJIC
Fan Motor Tee to Cooler Inlet
811-268C
HH1/2R2 048 3/4FJIC
Cooler Outlet to Oil Filter
811-268C
HH1/2R2 048 3/4FJIC
818-240C Re
v. A
To a
void Injur
y or
Mac
hine Dama
ge:
·Operate onl
y with
1000 rpm PT
O
CAUTION
85
8-005C
All dr
iveli
ne guar
ds,
tra
ctor
and
equipme
nt sh
iel
ds in
p
la
ce
PT
O pump assemb
ly securely
attached with t
orque ar
m and chain
RO
TA
TING DRIVELINE -
CONT
AC
T CAN CA
USE DEA
TH
KEEP A
W
AY
!
DO NO
T OPERA
TE
WITHOUT
-
DANGER
Figure 63:
401-847A and 411-165A Hydraulic Hose Routing
34673
36312
194
220
204
194
P
T
M
B
A
223
186
811-807C
811-268C
811-059C
841-815C
811-268C
841-849C
188
811-073C
220
223
204
186
188
186
194
194
