Install Oil Reservoir
Determine Reservoir Location
Refer to Figure 47 (top pane is a composite view of all
tool bar/truss configurations)
69. Determine the reservoir mounting location based on
the planter configuration and kit:
Kit Location Go To
401-845A Row Unit at Tool Bar page 42
401-846A Row Unit at Tool Bar page 42
401-847A Row Unit at Tool Bar page 42
401-848A Row Unit at Tool Bar page 42
401-849A Fertilizer Sub-Frame page 44
401-879A Mainframe Truss page 45
411-016A Below Main Seed Box page 46
411-035A Tongue at Hitch page 47
411-036A Tongue at Hitch page 47
411-037A Tongue at Hitch page 47
411-038A Tongue at Hitch page 47
411-163A Row Unit at Tool Bar page 42
411-164A Row Unit at Tool Bar page 42
411-165A Row Unit at Tool Bar page 42
411-166A Row Unit at Tool Bar page 42
411-167A Fertilizer Sub-Frame page 44
411-168A Mainframe Truss page 45
2
1
3
w
Figure 47: Reservoir Locations:
Tool Bar or Truss
Below Main Box
Tongue at Hitch
34657
36293
36295
4
858-0 04C
Read Owner ’s M anu al BEFO RE oper ating machine .
Keep tr actor at IDLI NG SPEED and slo wly engage PT O
to pre vent damage to Hydr aulic Motor Ke ep Radiator clean and free of f
oreign matter to
pre ve nt o ve rheating. Do NO T oper ate with h ydr aulic oil at or abo ve 180 °F.
HO T FLUID HAZARD
WARNING
858- 003 C
USE ANY HIGH Q
UALITY MINERAL BASED HYDR AULIC FLUID WITH A VISCOSITY RA TING
OF 10W -30. OIL MUST BE CLEAN AND FREE FR OM DIR T OR CONT AMINANT P AR TICLES TO
PREVENT D AMA GE TO PUMP AND MO
TO R.
REPLA CE FIL TER ELEMENT AFTER EVER
Y
150 OPERA TING HOURS OR 2
YEARS SER VICE.
LEVEL TO OLBAR BEFORE CHECKING OIL
LEVEL
CAP ACITY = 5.5 U
.S . GALS
OIL FILL LINE
5
1
1
1
1
2
3
4
5
5
5
5
1
1
1
1
2
3
